Your Advantage: No custom fees, no import tax inside the EU
The appliance includes the latest version of pfSense (preinstalled)
The 4 switch ports can be configured in the GUI.
IMIX: 314 Mb/s Firewall, 46Mb/s IPSec
SG-2100
In stock
Alternative Products
Beschreibung
SG-2100
The SG-2100 desktop system is a state of the art pfSense® Security Gateway appliance, featuring a dual core ARM design with crypto offload capability.
Built with performance, versatility, and low total cost of ownership in mind, the pfSense system SG-2100 meets the growing needs of organizations of all sizes.
This pfSense appliance can be configured as a firewall, LAN or WAN router, VPN appliance, DHCP Server, DNS Server, and IDS/IPS with optional packages to deliver a high performance, high throughput front-line security architecture at a excellent price per gigabit.
* Terms and Conditions at each Product Page
Hardware Specification
| CPU | Marvell Armada 3720 (88F3720) ARMv8-A 64-bit Cortex A53 @ 1.2GHz with NEON SIMD and FPU |
| CPU Cores | 2 Cores |
| Networking | 5x Gigabit Ethernet Ports: 1x Gigabit Ethernet (RJ45 / SFP Combo) 4x Gigabit Ethernet (Marvell 88E6141 switch, uplinked at 2.5 gbps) |
| Storage | 8GB eMMC Flash on board |
| Memory | 4GB DDR4 |
| Expansion | 1x M.2 ‚B‘ key sockets (SSD, LTE) 1x miniPCIe (WiFi) microSIM slot |
| Console Port | Mini USB |
| USB Ports | 1x 2.0 port |
| LED | 3 user-controllable full color RGB LEDs |
| Form Factor | Desktop H4.22cm x T10,8cm x B17,27cm |
| Cooling | Passiv |
| Power | External ITE P/S AC/DC 100-240V, 50-60 Hz, 12V 4.16A, threaded barrel connector AC Inlet: IEC320-C14 (3 PIN) German Powercord IEC320-C13 |
| Environmental | 0°C – 50°C |
| Certifications | CE, FCC (Class B), RoHS, UL, RCM, VCCI |
| Support |
Netgate Support available Voleatech Support available |
Best For
- Small Businesses
- Small Sized Business Networks
- Small to Medium Sized Branch Office
- Managed Service Provider / Managed Security Service Provider (MSP/MSSP) On Premise Appliance
- Teleworkers needing an “Always-Up” network or VPN connections
pfSense Features
pfSense is a free, open source firewall and router platform based on FreeBSD that is functionally competitive with expensive, proprietary commercial firewalls. pfSense can be configured as a stateful packet filtering firewall, a LAN or WAN router, VPN Appliance, DHCP Server, DNS Server, or can be configured for other applications and special purpose Appliances. This next generation pfSense security appliance features include:
- Stateful packet filtering firewall or pure router
- Routing policy per gateway and per-rule for multiple WAN, failover, load balancing
- Transparent layer 2 firewall
- Support for IPV6, NAT, BGP
- Captive portal with MAC filtering, RADIUS support, etc
- VPN: IPsec, OpenVPN
- Dynamic DNS client
- DHCP Server and Relay functions
- PPPoE Server
- Reporting and monitoring features with real time information
- and much more…
Low Total Cost of Ownership
- No artifical limits or add-ons required to make your system fully functional.
- No additional usage or feature based pricing. Enjoy unlimited users, unlimited firewall rules, unlimited IPsec tunnels, dual WAN, etc.
- Low power requirements to help save you money.
- No moving parts to wear out. This system is designed for a long deployment lifetime.
Growth with you
- From firewall to Unified Threat Management, get all the security features you need to protect your home or business.
- Flexible configuration and support for multi-WAN, high availability, VPN, load balancing, reporting and monitoring, etc.
- Add optional packages such as Snort or Suricata for IDS/IPS and network security monitoring, Squid for optimized content delivery and SquidGuard for anti-spam/anti-phishing and URL filtering.
- Maximum Active Connections: 8,000,000
Easy Gui Management
- Manage pfSense settings through our web-based GUI.
- No fumbling with a command line interface or typing arcane commands.
Secure Remote Access
- Connect via encrypted Virtual Private Networks (VPN) between your offices, let mobile workers connect security.
iperf3 (Bidirectional)
| Test | Speed |
| L3 Forwarding | 1.56 Gb/s |
| Firewall (10K ACLs) | 881 Mb/s |
| IPSec VPN (AES-128CBC, SHA1) | 118 Mb/s |
IMIX Traffic (Bidirectional)
| Test | Speed |
| L3 Forwarding | 842 Mb/s |
| Firewall (10K ACLs) | 314 Mb/s |
| IPSec VPN (AES-128CBC, SHA1) | 68 Mb/s |
1. Throughput Data are based on bidirectional traffic across all ports
2. Iperf3 traffic is TCP 1460 Bytes + TCP framing
3. IMIX Traffic is sets of 7x 40 Byte packets, 4x 576 Byte packets, 1x 1500 Byte packets and the Ethernet Frame Overhead
Source: Netgate USA
